Bluetooth Gateways

SL-600 Systech Angle.jpg
Bluetooth Icon.png

Perfect for Bluetooth connected health applications, or any application that requires connectivity with Bluetooth, the Systech® SysLINK® Modular IoT Gateway enables remote access to a wide variety of sensors and devices for monitoring and control purposes.  Key use cases include health & wellness, sports & fitness, and smart homes & buildings.  For connected health applications the gateway will read and monitor devices such as glucose monitors and pulse oximeters, and larger equipment such as a home dialysis machines.  For smart buildings, the gateway can monitor and control door locks, and participate in a beacon location application.

For system integrators and OEMs, the gateway can be customized for almost any application.  In addition to IoT functionality, the Gateway is a complete, commercial-grade router.

Hardware interface options are implemented with modular option cards, so the exact required interfaces can be supported off-the-shelf.  Support is provided for up to five simultaneous wireless interfaces in a single gateway.  The gateway is certified for all supported wireless options, including cellular certification for most carriers and most countries.

Software flexibility is provided by the Linux OS.  Full Linux access is provided, including the development toolchain, to enable installation of custom software for local, edge computing.  Tools are provided for a unified development environment supporting Java, C, C++, Python, and other Linux programming languages.

To assist managing large numbers of deployed gateways, a free cloud-based management solution is provided at no cost.  This tool provides the ability to remotely update any number of gateways with configuration updates, software updates, and security patches.  Customer-specific software may also be managed with this free tool.

Locally, on the gateway, Advanced Routing provides optional firewall capabilities.  A VPN option supports client and server modes using IPSec or OpenVPN.

Get your IoT application up and running quickly with the SysLINK Modular IoT Gateway.

White Label

  • System Integrators
  • OEMS

Includes

  • Linux OS
  • Free cloud-based management software
  • 5-year warranty

Optional Interfaces

Cellular Ethernet Wi-Fi Zigbee Z-Wave Bluetooth USB Serial GPIO Audio

Optional Features & Ordering Codes

Feature Ordering Code
Cellular, Verizon Cat-1 LTE -CV1
Cellular, Verizon, Cat-3 LTE -CV4
Cellular, AT&T/PTCRB, HSPA+ -CZH
Ethernet Ports (1 or 2) -E2
USB -U1
Temperature & Motion -TM
Wi-Fi -W
Bluetooth -BN
Audio -AU
Zigbee -ZB
ZWave -ZW
SD Card, 64GB -SD64

Modular Option Cards

Cellular

Wi-Fi

Z-Wave

zigbee

Bluetooth



SysLINK Modular IoT Gateway Models

 SL-500

SL-500

Simple Ethernet to cellular bridging applications.

  • Cellular or Wi-Fi
  • 1 or 2 Ethernet ports
  • 1 USB port
  • 1.11"x4.48"x3.83"
  • 5v power


SL-600 Systech Angle.jpg

SL-600

Wireless IoT applications.

  • Cellular
  • Wi-Fi
  • Bluetooth
  • 1 or 2 Ethernet ports
  • 1 USB port
  • Audio
  • 1 expansion option slots (Ex: Zigbee, Z-Wave)
  • 5.5"x4"x1"
  • 5v and 9-24v power options


SL-800

Serial or POTS IoT applications.

  • Cellular or Wi-Fi
  • 1 or 2 Ethernet ports
  • Serial
  • POTS
  • 1.31"x8"x4.63"
  • 5v power


SL-1500

Wireless IoT applications.

  • Cellular or dual-cellular
  • Wi-Fi
  • Bluetooth
  • 1 or 2 Ethernet ports
  • 1 USB port
  • 2 expansion option slots (Ex: Zigbee, Z-Wave)
  • 1.31"x8"x4.63"
  • 5v and 9-24v power options
